Genuine original product 1307K2408001 Electric Water Pump Assembly Hot Selling Bus & Truck Parts Accessory for Yutong Kinglong Model

Genuine product 1307K2408001 Electric Water Pump Assembly Hot Selling Bus Truck Parts Accessory for Yutong Kinglong Model

The Part Number 1307K2408001 is a high-performance 250W electric coolant pump specifically engineered for battery electric commercial vehicles, including electric buses and heavy-duty trucks. As a core component of the vehicle’s thermal management system, it ensures efficient cooling of critical powertrain components such as the traction motor, motor control unit (MCU), and high-voltage battery pack. Designed in alignment with 2026 industry trends toward intelligent, energy-efficient EV systems, this pump features a brushless DC (BLDC) motor, CAN/PWM controllability, and an IP67/IP6K9K-rated housing, making it ideal for harsh operating environments. With optimized flow performance, low noise, and built-in protection functions, the 1307K2408001 delivers reliable, long-life operation while contributing to extended vehicle range and improved system efficiency.

Quantity:
Availability:





Inquire Add to Basket

Model:
1307K2408001
Brand:
Yutong Bus Parts

Product Description

Attribute	Description
Product Name	High-Power Electronic Coolant Pump
Model Number	1307K2408001
Application Type	Electric Bus / Electric Truck Thermal Management System
Primary Function	Circulating Coolant for Motor, MCU, and Battery Cooling Loops
Motor Type	Brushless DC Motor (BLDC) – Maintenance-Free
Power Rating	250W (Medium-High Power Class for Commercial Vehicle Use)
Control Interface	CAN Bus (CAN 2.0B) and/or PWM Signal Input
Protection Rating	IP67 & IP6K9K (Dust-tight, Waterproof, Resistant to High-Pressure Washing)
Operating Voltage	24V DC (Compatible with Standard Heavy-Duty Commercial Vehicle Electrical Systems)
Mounting Orientation	Recommended Horizontal Installation for Optimal Air Bleeding

Parameter	Value / Description
Rated Power	250W
Operating Voltage	24V DC (Range: 20–32V)
Motor Technology	BLDC (Brushless DC), Electronically Commutated
Flow Rate	60 – 80 L/min (varies with system backpressure)
Head (Max Pressure Lift)	8 – 12 meters
Control Modes	- CAN Communication (CAN2.0B, customizable speed profiles) - PWM Input (e.g., 5–200 Hz, 50% duty cycle typical)
Speed Regulation	Variable Speed Based on Thermal Demand (Smart Control)
Ambient Temperature Range	-40°C to +85°C
Fluid Medium	Ethylene Glycol-Based Coolant (e.g., 50/50 water-glycol mix)
Insulation Resistance	> 100 MΩ at 500V DC
Vibration Resistance	Meets ISO 16750-3 (Automotive Environmental Conditions)
Expected Service Life	> 10,000 hours under normal operating conditions
