Why does Shacman Delong dominate the overseas heavy-duty truck market?

The SHACMAN Delong series of heavy-duty trucks—ranging from classic models like the F2000, F3000, H3000, X3000, and M3000/M3000S to the latest X5000/X5000S, H6000, and X6000—holds a pivotal market share in logistics and construction across the "Global South," including regions in Asia, Africa, and Latin America. From mining dump trucks in South America to long-haul tractors in the Middle East, Africa, and Southeast Asia, SHACMAN heavy-duty trucks consistently deliver efficient performance under the heavy loads and grueling conditions typical of these environments.

To ensure high vehicle uptime and minimize operational interruptions, local parts distributors and fleet operators typically maintain substantial inventories of frequently replaced wear parts.

This article provides a comprehensive breakdown of the core chassis wear parts most commonly purchased by customers in key overseas markets.

A. Braking System

The braking system is one of the fastest-wearing components, particularly on the mountainous roads of Latin America and under the heavy-load transport conditions found in Africa.

1. Brake pads/friction linings and brake shoes: Essential wear parts for the front and rear axles that require regular replacement. Key part numbers include:

I. Main Hande axle part numbers

II. Delong F3000 / X3000 / M3000 Hande 469 Axle

DZ9112340060 Rear brake shoe assembly

DZ9112340061 Rear brake shoe core

DZ9112340062 Rear brake lining

DZ9112340063 Rear brake lining

Hande 425 Wheel-end reduction axle

HD90129340422 Brake shoe assembly

HD90129340239 Upper brake lining

HD90129340240 Lower brake lining

Hande 35T Mining vehicle axle

DZ90149346032 35T Rear axle brake lining

Front axle braking

81.50200.6686 Front brake shoe assembly

III. Disc brake pads

Common export WVA universal codes + Shacman drawing numbers:

WVA29165, WVA29087

OEM part number: DZ96189340080 Disc brake pad assembly

III. Key points for procurement & export

Brake shoe (brake shoe assembly) = Shoe core + Rivets + Lining; Brake pad = Lining only

"A" and "B" pads are not interchangeable: DZ9112340062 (Upper/A) and DZ9112340063 (Lower/B) are a matched pair

Axle type must be confirmed: Part numbers for 469 single-reduction axle, 425 wheel-end reduction axle, and 35T mining axle are not interchangeable

IV. Quick selection guide

Delong F3000/X3000 standard-load tractor truck → DZ9112340060, DZ9112340061, DZ9112340062, DZ9112340063

Heavy-duty dump trucks & mining trucks with wheel-end reduction axles → HD90129340422 series (425 axle) parts

Front-axle disc brake models → WVA29165 brake pads

2. Brake discs/drums and brake chambers

Key part numbers include:

I. Brake drums

DZ9112340006: Rear brake drum for Hande 469/485 rear axle; Delong F3000/X3000 / New M3000 tractors

HD90129340571: Rear brake drum for Hande 425 wheel-end reduction axle; X3000 dump trucks and wide-body heavy-duty dump trucks

81.50110.0144: Front brake drum for Hande front steering drum-brake axle (older F3000 models)

DZ90149346027: 35T mining truck rear brake drum (Tongli mining trucks, Shacman wide-body mining trucks)

HD90149346058: 35T mining truck front brake drum

DZ9112440003: Lightweight rear brake drum (New M3000 lightweight 469 axle)

II. Brake discs

DZ96189340078: Front brake disc (disc brake rotor) for Delong X3000 / New M3000 disc-brake front axle

HD90009440032: Hande disc brake rotor (lightweight front disc for L3000 and Xuande series)

DZ9100410115: Front brake disc (older F3000 models) Models retrofitted with disc brakes

III. Rear spring brake chambers

DZ9112360390 Rear brake chamber (Left) – 469 Axle – F3000/X3000

DZ9112360391 Rear brake chamber (Right) – 469 Axle – F3000/X3000

DZ9112360395 Lightweight rear chamber (Left) – New M3000 Lightweight model

DZ9112360396 Lightweight rear chamber (Right) – New M3000 Lightweight model

HD95129360002 Front diaphragm brake chamber (Disc brake front axle, single-diaphragm type)

DZ9518936302127/30 Spring brake chamber – X5000 New model

AZ8800360130 Rear chamber (Left) – Suitable for Aolong, F2000

AZ8800360131 Rear chamber (Right) – Suitable for Aolong, F2000

3. ABS wheel speed sensors and air dryer cartridges. I. ABS Wheel Speed Sensor Part Numbers

DZ9100580214 ABS wheel speed sensor for Delong F3000/X3000/New M3000 (Hande 469 rear axle)

DZ95189584030 Wheel speed sensor (straight connector) for X3000/X5000 (disc-brake front axle)

HD90129580005 ABS sensor for Hande 425 hub-reduction axle (heavy-duty dump trucks, mining trucks)

HD90129580020 — Short-type ABS wheel speed sensor for New M3000 lightweight axle

DZ9100580215 ABS sensor bushing (for use with DZ9100580214 above) Sensor protective bushing for 469 axle

II. Air Dryer Cartridge Part Numbers

DZ96189360121 Air dryer cartridge for X3000 / New M3000 / L3000

DZ9100369472 Dryer cartridge for Delong F3000

DZ96259360173 New integrated oil-water separating dryer cartridge for X5000 (National VI models)

AZ9100368471 WABCO-style dryer cartridge (compatible with all WABCO air processing units)

III. Air Dryer Assembly

DZ96189360003 Four-circuit dryer assembly For X3000 / New M3000

DZ96189360063 New integrated dryer assembly For X5000 (National VI)

B. Drivetrain and Transmission Systems

Shacman Delong trucks are commonly equipped with Fast Gear transmissions (9JS, 12JS, and 16JS series) and 430mm push-type or pull-type clutches:

I. Clutch Driven Discs and Pressure Plates:

1. 430mm Standard Pull-Type (Universal for F3000/X3000/New M3000)

DZ9114160021: Compatible with WP10/WP12 engines; fits Delong F3000 and New M3000; 430mm pull-type; 2600Nm rating (standard-load tractor).

DZ9114160034: Compatible with Aolong and F2000 models; 395mm push-type pressure plate (legacy model).

DZ9X259160204: Compatible with X3000 (WP13 500/550 hp); high-torque 3100Nm rating; for high-horsepower National V/VI models.

DZ93189160360: Compatible with New M3000; lightweight 430mm pull-type pressure plate; designed specifically for lightweight models.

DZ91149160021: Compatible with X5000/X6000 AMT models; pressure plate designed specifically for AMT transmissions.

2. Clutch Driven Disc Assemblies

DZ9114160022: Compatible with F3000 and New M3000 (WP10/WP12); 430mm three-stage damping; popular universal model for standard-load applications.

DZ93189160202: Compatible with X3000 (WP12 / Cummins engines). ISM specifications; thickened friction disc designed for heavy-duty dump trucks and aggregate haulers.

DZ9X259160205 (compatible with X3000 WP13 / high-horsepower engines; pairs with DZ9X259160204 pressure plate; high-torque driven disc; must be replaced as a complete set).

DZ1560160020 (compatible with L3000 and lightweight M3000 models; 395mm; designed for lightweight, lower-horsepower tractor units).

DZ91149160020 (compatible with X6000 AMT models; vibration-damping driven disc designed specifically for AMT).

3. Quick-reference chart for frequently requested items (can be sent directly to customers for lookup).

Standard-load tractor units (F3000/X3000/New M3000)

Pressure plate: DZ9114160021; Driven disc: DZ9114160022

X3000 WP13 500+ (High-horsepower, National VI emission standard)

Pressure plate: DZ9X259160204; Driven disc: DZ9X259160205

X3000 Heavy-duty dump trucks / Aggregate haulers

Thickened driven disc: DZ93189160202

L3000 Lightweight 395mm kit; Driven disc: DZ1560160020

II. Release bearings and clutch master cylinder/slave cylinder (booster assembly). 1. Clutch Release Bearing Assembly

DZ9114160044 (Model 86CL6395F0): Small-bore, 430mm, pull-type; fits F3000 and new M3000 (WP10/WP12) standard-load tractors; matches DZ9114160021 pressure plate kit.

DZ9114160035 (Model 86NL6395FO): Small-bore, universal type; fits older Aolong, F2000, and lightweight M3000 (395mm clutch); compatible with both older push-type and pull-type systems.

DZ9X259160208: Large-bore, 430mm, pull-type bearing; fits X3000 (WP13 500/550 HP) Valeo clutch kit; matches DZ9X259160204 pressure plate.

DZ91149160030: AMT (automated manual transmission) release bearing assembly; fits X5000/X6000 automatic models; integrated hydraulic release unit.

DZ1560160030: 395mm lightweight release bearing; fits L3000 and low-horsepower lightweight tractors; designed specifically for 395mm clutches.

HD90129160011 (425): Heavy-duty release bearing for mining trucks (wheel-end reduction); fits X3000 wide-body dump trucks and 35T mining trucks; heavy-duty, thickened, wear-resistant design.

2. Clutch Master Cylinder

DZ9114230020: Threaded fluid port; fits F3000, older Aolong, and F2000 models.

DZ93189230090: Quick-connect fitting; fits X3000 (National V emission standard) models. Standard across the National VI lineup

DZ96189231520, new threaded port type; for M3000, M3000S, L3000

DZ97189230520, quick-connect fitting type; for new M3000 and X5000 lightweight cabs

3. Clutch slave cylinder

DZ93189230080, integrated clutch booster slave cylinder; for X3000 series

DZ9112230181, older split-type booster cylinder; for F3000 and older Aolong models with WP10 engines

DZ96189231530, lightweight booster slave cylinder; for M3000, L3000

DZ97259230022, X5000 National VI integrated slave cylinder; for X5000 and X6000 high-horsepower models

HD90129230033, heavy-duty mining truck clutch booster cylinder; for 425-series hub-reduction dump trucks and wide-body mining trucks

III. Transmission synchronizer assemblies, gears, bearings, and oil seals. 1. Synchronizer assembly part numbers (complete set)

1) Universal 12-speed (12JS160T/12JSD200T; F3000/X3000 standard-load tractor units)

12JS160T-1701170 Main box 1st/2nd gear synchronizer assembly

12JS160T-1701180 Main box 3rd/4th gear synchronizer assembly

12JS160T-1701190 Main box 5th/6th gear synchronizer assembly

12JSD160T-1707140-2 Auxiliary box high/low range synchronizer assembly

2) High-horsepower heavy-load 12JSDX240T (WP13 500/550 hp; X3000/X5000)

12JSDX240T-1701170 1st/2nd gear synchronizer assembly

12JSDX240T-1701180 3rd/4th gear synchronizer assembly (mining truck)

12JSDX240T-1701190 5th/6th gear synchronizer assembly

12JSDX240T-1707140 Auxiliary box synchronizer assembly

3) 9-speed 9JS135/9JS180 (Older F3000, Aolong, lightweight M3000)

JS135T-1701170 1st/2nd gear synchronizer

JS135T-1701180 3rd/4th gear synchronizer

JS135T-1707140 Auxiliary box synchronizer assembly

4) 16-speed 16JSD240T (High-horsepower long-haul standard-load; X6000)

16JS200T-1701170 (1st/2nd ...gear), 16JS200T-1707140 (Auxiliary section synchronizer)

2. Transmission core gear part numbers (Input shaft / Main shaft / Countershaft / Auxiliary section gears)

1) 12JSD200T standard gears

12JSD200T-1701116 Input shaft gear

12JSD200T-1701105 Main shaft assembly / Main shaft low-gear gear

12JSD200T-1701050 Countershaft 3rd gear

12JSD200T-1707106 Auxiliary section main shaft reduction gear

12JSD200T-1707056-1 Auxiliary section welded shaft (long)

2) 12JSDX240T heavy-duty gears

12JSDX240T-1701105 Main shaft; 12JSDX240T-1701051 Countershaft 4th gear

3) 9JS135 legacy gears

JS119-1701109 Main shaft low-gear gear; JS119-1701110 Main shaft reverse gear

3. Transmission-specific bearing models (Universal bearing code + Compatible models)

1) Input shaft bearing (Universal for all 12-speed models)

150212K / 6212-ZNB Input shaft pilot bearing (Standard on F3000/X3000)

2) Main shaft / Countershaft roller bearings

42308E Countershaft rear short cylindrical roller bearing (Universal for 12/9-speed models)

370309Y Countershaft front ball bearing (9JS180)

3) Auxiliary section welded shaft bearing

NF308EM/C9 Rear bearing for the main shaft (8/9/12-speed models)

4) Rear bearing for the output shaft

6213N Transmission output shaft bearing

4. Complete set of transmission oil seals

1) Input shaft oil seal (front oil seal for the clutch housing; high-demand item)

10641041-2 Fast Gear 12-speed input shaft oil seal (universal for F3000/X3000 series); dimensions: 47.63 x 65.07 x 6.35

2) Rear output shaft oil seal (driveshaft end)

12JS160T-1707023 12-speed output shaft oil seal

JS135T-1707023 9-speed output shaft oil seal

3) Auxiliary gearbox high/low range cylinder O-ring and housing oil seal

14344 Auxiliary gearbox cylinder O-ring (9JS135)

IV. Driveshaft cross-and-bearing kit (universal joint) and driveshaft center support bearing. 1. Driveshaft Cross Assembly (Universal Joint Cross Shaft Assembly) Part Numbers

1) Vehicle Driveshaft Cross Assemblies

DZ9114312067: Spec 57×152 (68 cross); fits F3000, New M3000 469 standard-load tractor units

DZ9112312080: Spec 57×166 (Reinforced); fits X3000 (WP12/WP13 engines, 500/550 hp)

DZ9X259312005: Spec 62×172 (Widened cross); fits X5000/X6000 National VI high-horsepower tractor units

1903611080: Spec 52×140; fits Aolong, F2000 (older models with narrow-body driveshafts)

2) Hande Inter-axle Differential Cross Shafts

HD469-2510014: Intermediate axle inter-axle differential cross shaft; fits Hande 469/485 single-reduction axles

DZ9112320215: Wheel differential cross shaft; fits 469 and 425 series (universal for wheel-end reduction axles)

HD90129320039425: Mining truck inter-axle cross shaft; fits wide-body dump trucks and 35T heavy-duty mining trucks

2. Driveshaft Center Support Bearings

1) Integrated Center Support Assemblies

DZ9112314060: Spec 65mm (Single bearing); fits F3000, older M3000 models

DZ9112314105: Spec 75mm (Reinforced bearing); fits full X3000 series, New M3000S

DZ96189310012: Spec 80mm (Widened heavy-duty support); fits X5000 National VI / Sand & Gravel Dump Trucks

HD90129310026 (85mm spec): Mining-grade center support for wide-body mining trucks with 425-series wheel-end reduction axles

3) Individual center support bearing inserts

6213N: DZ9112314105 (Bearing for hanger bracket)

6215: DZ96189310012 (Bearing for heavy-duty support)

51312 Thrust Bearing: Specific to older Aolong / F2000 center supports

Export Quick-Reference Chart

1. Standard-load tractor: F3000 / New M3000 (90% of standard orders)

Universal joint cross: DZ9114312067

Center support assembly: DZ9112314105

2. X3000 WP13 500 + High-horsepower long-haul tractor

Universal joint cross: DZ9112312080

Center support assembly: DZ96189310012

3. 425-series wheel-end reduction heavy-duty dump truck / Mining truck

Universal joint cross: DZ9112312080

Mining-grade center support: HD90129310026

Inter-axle differential cross shaft: HD90129320039

4. Older Aolong / F2000 models

Universal joint cross: 1903611080

Center support: DZ9112314060

C. Steering System

I. Steering Tie Rod / Drag Link Ball Joint Assemblies:

1. Steering Drag Link Assemblies

DZ9118430026: Fits F3000 and older/new M3000 9.5T standard-load tractor trucks

DZ97319430604: Fits X3000 (WP12/WP13, 500/550 hp) with 9.5T disc-brake front axle

DZ96189430432: Fits new M3000S and L3000 lightweight 7.5T front axle

DZ9718430403: Fits X5000/X6000 (National VI compliant) 9.5T models

HD90129430044: Fits 425 wide-body wheel-end reduction dump trucks and 35T mining trucks

199100430014: Fits older Aolong and F2000 (Steyr-based) 7.5T front axle

2. Independent Ball Joint Assemblies (for Drag Link Ends)

DZ9118430027: Fits drag link DZ9118430026

DZ9118430028: Fits drag link DZ9118430026

DZ97319430605: Fits drag link DZ97319430604

DZ97319430606: Fits drag link DZ97319430604

3. Steering Tie Rod Assemblies

DZ9100430039: Fits F3000/X3000 9.5T drum-brake front axle (universal best-seller)

81.46711.6725: Fits X3000 disc-brake front axle

HD90009430006: Fits new models M3000, L3000 7.5T lightweight front axle

HD90129430051425: Widened tie rod for mining trucks and heavy-duty dump trucks

DZ96259430110X5000: Reinforced tie rod (9.5T) for new National VI models

4. Independent tie rod ball joint assemblies (Left/Right)

Distinction: Left ball joint (driver side) vs. Right ball joint (passenger side); threads are non-interchangeable (LH/RH threading). Part numbers for left/right ball joints and corresponding tie rod assemblies:

HD90009430037, HD90009430038, DZ9100430039

HD90009430007, HD90009430008, HD90009430006

HD90129430052, HD90129430053, HD90129430051

Export Quick-Reference Chart

1. Standard-load tractor: F3000 / Older M3000 (90% of standard orders)

Drag link assembly: DZ9118430026

Tie rod assembly: DZ9100430039

Tie rod ball joint (Left): HD90009430037 / (Right): HD90009430038

2. X3000 WP13 High-horsepower model with disc brakes

Drag link assembly: DZ97319430604

Tie rod assembly: 81.46711.6725

3. New M3000/L3000 Lightweight models 7.5T

Drag link assembly: DZ96189430432

Tie rod assembly: HD90009430006

4. 425 Wheel-end drive dump truck / Wide-body mining truck

Drag link assembly: HD90129430044

Tie rod assembly: HD90129430051

II. Power steering pump and steering drag link assembly. 1. Power Steering Pump (Hydraulic Steering Pump) Core Part Numbers

1) Weichai WP10 Engine

DZ9100130027: Fits Delong F3000 WP10 (336/375 hp)

DZ9100130038: Fits F3000 heavy-duty dump truck (WP10)

612600130140: Fits WP10 (universal replacement number)

2) Weichai WP12 Engine (Main model for X3000 standard-load tractor units)

DZ95259470500: Fits X3000 WP12 (375/430 hp, standard configuration)

DZ95259470501: Fits X3000 high-end version (ZF OEM)

612630030047: Fits WP12 (universal export replacement number)

3) Weichai WP13 High-Horsepower (X3000/X5000 National V/VI, 500/550 hp)

DZ9X259470200: Fits X3000 WP13 (500/550 hp)

DZ97259470300: Fits X5000 National VI high-end high-horsepower models

1001839624: Fits WP13

4) New M3000/L3000 Lightweight Series (WP7/WP8 lower horsepower)

DZ96189470500: Fits New M3000/L3000 lightweight models (7.5T front axle)

DZ96259470200: Fits New M3000S (National VI new model)

5) Cummins Engine Applications (ISM11/M12 X3000 export version)

DZ93259470210: Fits X3000 Cummins ISM11 Engine

DZ93259470300 (Compatible with National VI Cummins M12)

6) Legacy Aolong / F2000 (Old-style steering pump)

DZ9114130001: Legacy Steyr WP10 (Old-style power steering pump, figure-8 flange mount)

2. Steering drag link assembly

DZ9118430026 (Compatible with F3000, legacy M3000; 9.5T standard load)

DZ97319430604 (Compatible with X3000 WP12/WP13; 9.5T disc-brake front axle)

DZ96189430432 (Compatible with new M3000S, L3000; 7.5T lightweight)

DZ9718430403 (Compatible with X5000/X6000; National VI reinforced version)

HD90129430044 (Compatible with 425 wide-body wheel-end reduction dump truck, 35T mining truck)

199100430014 (Compatible with legacy Aolong, F2000 Steyr; 7.5T)

Export Quick-Reference Chart (High-Frequency Items)

Standard-load tractor F3000 WP10

Power steering pump: DZ9100130027 / Weichai Part No. 612600130140

Steering drag link: DZ9118430026

X3000 WP12/WP13 High-horsepower

Power steering pump: DZ95259470500 (Duer) / DZ9X259470200 (WP13)

Steering drag link: DZ97319430604

New M3000/L3000 Lightweight

Power steering pump: DZ96189470500

Drag link: DZ96189430432

III. Steering Knuckle Kingpin and Bushing Repair Kits

1. Kingpin repair kit assembly

1) 9.5T Hande front axle (F3000/X3000/X5000)

HD90009410357 (fits X3000/X5000 National V/VI); single kingpin part no. HD90009410062, bushing part no. HD90009410063

81.44205.0055 (fits Delong F3000 older drum-brake front axle); single kingpin part no. 81.44205.0051, bushing part no. 81.44205.0052

2) 7.5T lightweight front axle (New M3000/L3000/M3000S)

HD95009410054 (fits New M3000, L3000 lightweight 7.5T); single kingpin HD95009410054, bushing HD95009410053

81.44205.0057 (fits older Aolong, F2000, older M3000); single kingpin 81.44205.0053, bushing 81.44205.0054

3) 5.5T light-duty front axle

Repair kit assembly: HD90009410053

Older 5.5T model: HD90009410337

4) 425 Heavy-duty front axle with wheel-end reduction for mining applications

Kingpin repair kit assembly: HD90129410046

Heavy-duty oversized kingpin: HD90129410047

Thickened wear-resistant copper bushing: HD90129410048

2. Steering knuckle assembly part numbers

HD90009413180: Fits F3000 and older X3000 drum-brake front axles

HD90009413181: Fits X3000/X5000 disc-brake front axles

HD95009413001: Fits new M3000/L3000

HD90129413009: Fits wide-body dump trucks and heavy-duty mining trucks

81.44202.0003: Fits F3000

Individual components

1) Steering kingpin (single unit)

HD90009410062: 9.5T new standard kingpin Φ53.5×232

HD95009410054: 7.5T lightweight kingpin Φ50×226

HD90129410047: Mining truck (425) heavy-duty oversized kingpin Φ56×245

81.44205.0051: Older 9.5T F3000 kingpin

2) Kingpin copper bushing (upper and lower pair)

HD90009410063: 9.5T new copper bushing

HD95009410053: 7.5T Lightweight Bushing

HD90129410048: Thickened, wear-resistant bushing for mining trucks

81.36305.0016: Universal bushing for older Hande axles

3) Associated small wear parts (included in repair kit)

Kingpin upper oil seal: HD95009410055 (7.5T), HD90009410064 (9.5T)

Kingpin thrust bearing: 91754 (9.5T universal), 91753 (7.5T)

Adjustment shim / Thrust washer: HD95009410161

D. Suspension System

I. Leaf Springs and U-bolts:

1. Leaf Spring Assemblies

1). Delong F3000 (469 Axle) Standard-Load Tractor

DZ9114520002 Front Leaf Spring Assembly (Left) – 10-leaf standard front spring

DZ9114520003 Front Leaf Spring Assembly (Right) – 10-leaf standard front spring

DZ9114526012 Rear Leaf Spring Assembly – 12-leaf heavy-duty rear spring

2). X3000 WP12/WP13 High-Horsepower Tractor

DZ95259520401 X3000 Front Leaf Spring Assembly

DZ95259520402 X3000 Rear Leaf Spring Assembly

3). New M3000 / L3000 Lightweight Standard-Load

DZ96189520010 New M3000 Front Leaf Spring Assembly

DZ96189520011 New M3000 Rear Leaf Spring Assembly

4). X5000 National VI New High-Horsepower Dump Truck

DZ97259520801 X5000 Front Leaf Spring Assembly

DZ97259520802 X5000 Rear Leaf Spring Assembly

5). 425 Wide-Body Mining Truck (Wheel-End Reduction) / 35T Mining Truck

HD90129520034 Mining Truck Front Leaf Spring Assembly

HD90129520035 Mining Truck Rear Leaf Spring Assembly

2. U-bolts

1). F3000 Standard-Load Tractor

DZ9114526033 Front Leaf Spring U-bolt M24×500

DZ9114526027 Rear Leaf Spring U-bolt U-bolt M27×555

2). X3000 Lightweight (Low-leaf-count spring specific)

DZ95259520403 X3000 Rear spring U-bolt M24×540

DZ95259520404 X3000 Front spring U-bolt M22×460

3). New M3000 / L3000

DZ96189520020 Front leaf spring U-bolt

DZ96189520021 Rear leaf spring U-bolt

4). X5000 New National VI Model

DZ97259520913 Front spring U-bolt

DZ97259520914 Rear spring U-bolt

5). 425 Mining Truck Heavy-duty Reinforced U-bolt

HD90129520036 Mining truck front spring U-bolt M30×620

HD90129520037 Mining truck rear spring U-bolt M30×680

6). Legacy Aolong F2000

DZ9100520023 Aolong front spring U-bolt

DZ9100520038 Aolong rear spring U-bolt

II. Shock Absorbers, Cab Airbags, and Rubber Bushings

1. Cab Airbags

1) Delong X3000

DZ14251430020 Cab front suspension airbag

DZ14251440020 Cab rear suspension airbag

DZ14251440060 X3000 New reinforced rear airbag

2) New M3000 / M3000S / L3000 Lightweight

81.41722.6051 Front suspension airbag DZ15221440300 Rear suspension air bag

DZ15221440400 Rear suspension air bag

DZ15221440800 Thickened heavy-duty rear air bag

3) Delong F3000 / Older Aolong F2000

81.41722.6051 F3000 Front suspension air bag

81.41722.6052 F3000 Rear suspension air bag

DZ1600440002 Aolong older-style rear air bag

4) X5000 (New National VI model)

DZ14251430025 Front air bag

DZ14251440025 Rear air bag

5) Lift axle air suspension air bag

DZ95259440307 Drive axle air spring;

DZ95259440319 Lift axle intermediate air bag

2. Shock absorbers (categorized into cab hydraulic shock absorbers, chassis leaf spring shock absorbers, and seat damping shock absorbers)

1) Cab hydraulic shock absorbers (X3000)

DZ14251430500 Front shock absorber; DZ14251440500 Rear shock absorber

New M3000

DZ15221430580 Front shock absorber; DZ15221440580 Rear shock absorber

F3000 (Older model)

DZ13241440100 Rear cab shock absorber; DZ1640440015 Older-style rear shock absorber

2) Chassis leaf spring shock absorbers (between frame and leaf springs)

X000: DZ95259680103 Rear chassis shock absorber

New M3000: DZ95259680013 Chassis shock absorber

3000 Standard-load towing: DZ91149680002 Shock absorber (universal for front and rear)

425 Mining truck heavy-load shock absorber: HD90129680041 Reinforced (thicker and longer) shock absorber

3) Seat air-cushion damping shock absorber

DZ14251510083 X3000 Main seat damping shock absorber

3. Rubber bushings for all vehicle models

1) Cab suspension/tilt rubber bushings & hydraulic lock bushings

DZ15221440094 Cab hydraulic lock rubber bushing (fits X3000 / New M3000)

DZ13241430085 Cab front suspension bracket bushing (fits all F3000 models)

BZ50034120 Xuande X6 tilt bracket rubber bushing (fits Xuande series)

2) Leaf spring rubber bushings (leaf spring pin bushings)

F3000: DZ9114520008 Leaf spring bushing (universal for front and rear)

X3000: DZ95259520672 Leaf spring shackle bushing

Mining truck 425 axle: HD90129520038 Thickened heavy-load leaf spring bushing

3) Stabilizer bar / balance bar bushings (split bushings, hanger bushings)

SZ965000702 X3000 Stabilizer bar split rubber bushing

81.43704.0074 F3000 Front stabilizer bar bushing

81.96210.0450 Balance bar hanger rubber bushing (universal for all models)

81.96210.0508 F3000 Balance shaft bushing

4) Engine and transmission mounting pads (engine mounts)

X3000: DZ97259590209 Engine rear mounting cushion

New M3000: DZ96259590113 Front-left engine mount / DZ96259590114 Front-right engine mount

Transmission support cushion: DZ93259590003 Universal transmission mounting cushion (all series)

4. Quick-reference chart for export models

1) Delong F3000 Standard-load tractor

Cab front air spring: 81.41722.6051; Rear air spring: 81.41722.6052

Cab shock absorber: DZ13241440100; Leaf spring bushing: DZ9114520008

Stabilizer bar bushing: 81.43704.0074

2) X3000 WP12/WP13 High-horsepower tractor

Front air spring: DZ14251430020; Rear air spring: DZ14251440020

Cab shock absorber: DZ14251430500/440500; Stabilizer bar bushing: SZ965000702

3) New M3000 / L3000 Lightweight model

Front air spring: 81.41722.6051; Rear air spring: DZ15221440400

Chassis shock absorber: DZ95259680013; Hydraulic lock bushing: DZ15221440094

4) 425 Wide-body heavy-duty mining truck

Chassis shock absorber: HD90129680041; Leaf spring bushing: HD90129520038

III. Balance shaft bushings and thrust rod bushings (V-type thrust rod / thrust rod assembly). 1. Balance Shaft Bushing OEM Part Numbers

1) Delong F3000 & Older M3000 (469 Split-type Balance Shaft)

Main flange bushing part number: 81.96210.0508; matching spacer/small bushing part number: 81.96210.0507. These two bushings must be replaced as a matched pair; compatible with 9.5T Hande single-reduction rear axle standard-load tractors.

2) Delong X3000 WP12/WP13 (Lightweight/Low-leaf-count Spring Balance Shaft Bushing)

Standard lightweight rubber bushing part number: DZ95259520828 (fits all National V X3000 long-haul standard-load tractors); National VI X5000 reinforced/thickened bushing part number: DZ97259520932 (features multi-layer steel wire reinforcement; fits 500/550 hp high-horsepower models).

3) New M3000, M3000S, & L3000 (7.5T Lightweight Narrow-body Balance Shaft Bushing)

Specialized lightweight narrow-dimension bushing part number: DZ96189520043 (smaller dimensions; not interchangeable with 9.5T model bushings; fits urban standard-load and "Green Channel" lightweight models).

4) 425 Wheel-end Reduction Wide-body Dump Truck & 35T Mining Truck (Heavy-duty Balance Shaft Bushing)

Heavy-duty mining-grade thickened wear-resistant bushing part number: HD90129520040 (thickened rubber with multi-layer steel wire skeleton; designed to withstand the rough terrain and heavy loads of mining operations; fits Hande 425 wheel-end reduction axles). 5) Integrated balance shaft bushings for older Aolong and F2000 Steyr models

Rubber bushing for the older integrated balance shaft assembly (Part No.: 199014520191): Fits only early Steyr-platform models; market demand for replacements is relatively low.

2) Thrust rod bushings (torsion rubber inserts; categories include upper thrust rod, lower thrust rod, and V-type thrust rod bushings) – OEM part numbers

1) Universal bushings for F3000 and older M3000 models (60mm tube thrust rods)

Upper thrust rod torsion rubber insert (control arm bushing) Part No.: DZ91259525274-1; matches upper thrust rod assembly DZ91259525274;

Lower thrust rod torsion rubber insert Part No.: DZ91259525277-1; fits rear axle lower control arm;

V-type thrust rod large rubber bushing Part No.: DZ91259525282-1; larger in size; not interchangeable with straight thrust rod bushings.

2) Bushings for X3000 and X5000 models (new lightweight 70mm tube thrust rods)

X3000 upper thrust rod bushing Part No.: DZ95259525041;

X3000 lower thrust rod bushing Part No.: DZ95259525042;

X5000 National VI reinforced V-type thrust rod bushing Part No.: DZ97259525105; features improved tear-resistant rubber material; suitable for high-horsepower dump trucks and long-haul tractor units. 3) New M3000 & L3000 Lightweight Torque Rod Bushings

Universal bushing for lightweight upper/lower straight torque rods (Part No.: DZ96189525020); V-type torque rod bushing specifically for the M3000S (Part No.: DZ96189525023), compatible with lightweight chassis featuring low-leaf-count spring suspension.

4) Heavy-Duty Torque Rod Bushings for 425-Series Wide-Body Mining Dump Trucks

Thickened, heavy-duty rubber bushing core for mining truck upper torque rods (Part No.: HD90129525012); reinforced bushing for mining truck V-type torque rods (Part No.: HD90129525013), featuring thickened inner and outer steel sleeves to resist cracking and deformation under heavy mining loads.

E. Drive Axle and Wheel Hub Assembly

1. Wheel Hub Bearings and Oil Seals

1. Delong F3000 and older M3000 models: Hande 469 single-reduction rear axle

Front wheel 9.5T steering axle hub bearings and oil seals

Front inner bearing model: 32310; front outer bearing model: 33216X2-1; front hub oil seal part number: 06.56289.0267 (spec: 100x130x12, double-lip structure), compatible with all F3000 drum-brake front axles.

469 rear axle split-type hub bearings and composite hub oil seals

Rear hub inner bearing: 32222; rear hub outer bearing: 33220; rear axle left hub oil seal part number: DZ90129340063; rear axle right hub oil seal part number: DZ90129340064 (these two seals are a matched pair and include internal O-rings); integrated rear hub oil seal part number: DZ9112340227; oil slinger for older split-type seal part number: DZ9112340053.

2. X3000 and X5000 models: New Hande 469/485 lightweight axles (National V / National VI high-horsepower tractor units)

Front wheel hub bearing unit and oil seal (specific to disc brakes)

Maintenance-free front hub bearing unit assembly part number: F805733; matching front hub oil seal part number: HD95129320010; split-type front inner bearing (32310) and outer bearing (33216X2-1) are interchangeable with bearings from the older 9.5T front axle. Rear axle maintenance-free hub bearings and new split-type oil seals

Rear wheel maintenance-free hub bearing unit 363019; X3000-specific rear wheel split hub oil seal (universal size 13216710.5, no independent DZ part number); National VI X5000 reinforced rear hub oil seal (part no. DZ97259340120), featuring a double-lip fluoroelastomer design for high-temperature resistance and leak prevention.

3. New M3000, M3000S, and L3000 7.5T lightweight narrow-body axles

Front wheel lightweight hub bearings and oil seals

Front wheel inner and outer bearings 32219 and 32017 (narrow-body specific models); front hub oil seal part no. DZ96189320007 (smaller dimensions than the 9.5T front axle oil seal; not interchangeable).

Rear axle lightweight hub bearings and oil seals

Rear wheel maintenance-free bearing unit BY363021YAXLB; rear axle integrated hub oil seal part no. DZ96189340085 (compatible with lightweight chassis featuring few-leaf springs).

4. 425 wide-body dump trucks with wheel-end reduction and 35T heavy-duty mining axles

Mining truck front axle oversized hub bearings and thickened oil seals

Front axle heavy-duty bearings 32311 and 33217 (enlarged specifications); mining truck front hub oil seal part no. HD90129320021 (thickened fluoroelastomer material with reinforced skeleton). 425 Rear Axle Wheel-End Hub Bearings and Oil Seals

Wheel-end inner bearing 32224, wheel-end outer bearing 33222 (thickened heavy-duty bearings); rear axle wheel-end left hub oil seal HD90129340498, rear axle wheel-end right hub oil seal HD90129340497 (includes matching dedicated dust cover assembly); rear axle main hub integrated oil seal (Part No. HD90129340563), designed for heavy-duty mining operations with dust and mud/sand protection.

5. Older Aolong and F2000 Steyr-style Axles

Front Wheel Hub Bearings and Oil Seals

Front wheel bearings 32309, 33215; front wheel oil seal (Part No. 199012340111), standard single-lip rubber oil seal.

Rear Axle Hub Bearings and Oil Seals

Rear axle bearings 32220, 33218; rear wheel integrated hub oil seal (Part No. 199012340113), matching wheel-end spacer sleeve (Part No. 199012340114).

III. Differential Planetary Gears, Cross Shafts, Side Gears, and Input/Output Shaft Oil Seals

1. Hande 469 Single-Stage Rear Axle

Inter-wheel Differential Internal Gear Components

Side gear (Part No. HD469-2403015) for rear axle inter-wheel differential; 2 pieces required per differential assembly. Inter-axle differential side gear (Part No. HD469-2510016) for the middle axle through-shaft differential assembly.

Planetary gear (Part No. HD469-2403017) with matching dedicated thrust washer (Part No. HD469-2403018); 4 planetary gears required per differential assembly. Inter-wheel differential cross shaft (long version), part no. HD469-2403021, fits the 469 rear axle inter-wheel differential; inter-axle differential cross shaft, part no. HD469-2510014, designed for the middle axle's through-shaft inter-axle differential.

Main Reducer Oil Seals (Input/Output)

Main reducer drive pinion input oil seal (pinion seal), part no. DZ9112320920, specification 85x105x18, installed at the main reducer flange input end; universal across the 469 series;

Middle axle through-shaft output oil seal, part no. HD95129320010, fits the output end of the 469 middle axle through-shaft;

Older split-type through-shaft oil seal, part no. 06.56279.0335, dimensions 75x95x10; fits only early F3000-series older 469 middle axles.

2. Hande 485 Lightweight Single-Reduction Axle (for X3000/X5000 National V high-horsepower tractor units)

Differential Gear Kit

Rear axle inter-wheel side gear (half-shaft gear) 81.35106.0037; features a reinforced structure with thickened tooth roots; fits models equipped with high-torque WP13 engines;

485 axle planet gear 81.35106.0040, with matching shim 81.35106.0042;

Inter-wheel cross shaft 81.35106.0041; inter-axle differential cross shaft HD90009320401. Final Drive Oil Seals

Drive pinion input oil seal DZ972593200101: Fluororubber double-lip design; high-temperature resistant, specifically for National VI emission standards.

Through-shaft output oil seal HD95129320011: Features a widened dust lip; compatible with X5000 lightweight intermediate axles.

3. 7.5T Lightweight Narrow-Body Axle (New M3000, M3000S, L3000)

Differential Gear Components

Lightweight side gear HD95009320026: Compact gear disc design suited for lightweight chassis with low-leaf-count suspension.

Planet gear HD95009320027: Paired with thin thrust washer HD95009320028.

Short inter-wheel spider HD95009320029: Smaller dimensions than the 469-series axle spider; not interchangeable.

Oil Seal Accessories

Final drive input pinion oil seal DZ96189320090: Reduced outer diameter, specifically for lightweight models.

Through-shaft output oil seal HD95009320012: Compatible with single-stage lightweight intermediate axles.

4. Hande 425 Mining Axle with Wheel-End Reduction (Wide-body dump trucks, 35T heavy-duty mining trucks)

Heavy-Duty Differential Gear Components

Thickened heavy-duty mining side gear HD90129320045: Larger gear module to withstand impact loads in mining environments.

Heavy-duty planet gear HD90129320046: Thickened thrust washer HD90129320047.

Reinforced inter-wheel spider HD90129320048; inter-axle differential spider HD90129320049. Main Reducer Input and Output Oil Seals

Mining truck main reducer input oil seal (HD90129320050): Triple-lip fluoroelastomer (FKM) construction; designed to prevent mud and sand ingress.

425-series axle through-shaft output oil seal (HD90129320051): Features an extended dust-proof outer ring; suitable for harsh construction site conditions.

5. Older Steyr Aolong F2000 / Legacy Drive Axles

Differential Gear Components

Legacy rear axle side gear (199012320066); planet gear (199012320067); legacy spider gear shaft (199012320068).

Oil Seals

Main reducer input oil seal (199012320070): Legacy single-lip standard rubber design; through-shaft oil seal (06.56289.0331): Compatible only with early Steyr-platform models.

IV. Wheel Hub Bolts and Nuts:

1. Hande 469 Single-Stage Rear Axle

Front wheel hub bolt (Part No. DZ9100410103): Fits 9.5T drum-brake/disc-brake front steering axles; thread specification M22×1.5; matching front wheel hub nut (Part No. 81.45501.0102): Integrated nut with anti-slip washer.

Standard rear wheel hub bolt (Part No. DZ9112340123): Standard-load, short-type knurled bolt; extended heavy-load rear wheel hub bolt (DZ9112340337): Suitable for aggregate dump trucks using thicker steel rims; matching rear wheel hub nut (DZ95189611300): Dual-layer locking structure to prevent loosening under heavy loads. For older Aolong and F2000 models (sharing the same "469" axle), the rear wheel hub bolt is a universal part (Part No. 199012340123); this is an older-style smooth-shank bolt (non-knurled) paired with the older-style single nut (Part No. 199012340124).

2. Hande 485 Lightweight Single-Reduction Axle

Front axle lightweight hub bolt (Part No. HD90009320072): Fits new disc-brake front axles; shorter than the 469 front wheel bolt. Paired with a thickened, dust-proof front wheel nut (Part No. HD90009320073) featuring a rust-resistant fluoropolymer coating.

Rear axle extended bolt for maintenance-free hubs (Part No. HD90009348159): Fits 485 lightweight hub units. Paired with a heavy-duty dual-locking nut (Part No. H150A2289BZF3) designed for high-torque WP13 engine models; not interchangeable with 469 axle nuts.

3. 7.5T Lightweight Narrow-Body Axle (New M3000, M3000S, L3000 models)

Front wheel small hub bolt (Part No. DZ96189320031): M20×1.5 thread; smaller dimensions than bolts for 9.5T models. Paired with a small flange nut (Part No. DZ96189320032) designed for lightweight, narrow-profile steel rims.

Rear axle lightweight short hub bolt (Part No. DZ96189340091): Paired with an integrated anti-loosening nut (Part No. DZ96189340092); designed for chassis with low-leaf-count suspension; load capacity is lower than that of 469/485 axle bolts. 4. Hande 425 Mining Axle with Wheel-End Reduction (for wide-body dump trucks and 35-ton heavy-duty mining trucks)

Front axle wheel hub bolts (HD90129320095): Thickened and lengthened, featuring enlarged M24×1.5 threads to withstand impact loads in mining environments; paired with thickened and widened dust-proof nuts (HD90129320096).

425 Rear axle (wheel-end reduction) heavy-duty hub bolts (HD90129340462): Lengthened with a knurled anti-slip design; paired with specialized double-layer locking nuts (HD90129340463) to prevent loosening on muddy job sites, and used alongside axle-end locking nuts (HD90129340451)—specifically slotted round nuts for hub spindle/bearing positioning, distinct from wheel-securing nuts.

5. Differentiation of general-purpose small components

Slotted round nuts for axle ends (bearing positioning nuts, not wheel nuts): Universal for 469 axles (DZ9114320901), 485 axles (DZ97259320102), 7.5T lightweight axles (DZ96189320040), and 425 mining axles (HD90129340451);

Standard flat washers for hub bolts (Q40322): Universal for the entire M22 bolt series; M20 lightweight bolts use Q40320 washers.
