1000993537
Tonly Mining Dump Trucks
| Attribute | Specification |
|---|---|
| Part Number | 1000993537 |
| Manufacturer | Weichai Power Co., Ltd. |
| Component Name | Exhaust Gas Turbocharger with Pneumatic Wastegate |
| Engine Compatibility | Weichai WP13 Series (480hp, 500hp, 550hp); also compatible with WP12 platforms |
| Application Type | Heavy-Duty Commercial Vehicles, Mining Trucks, Construction Equipment |
| Turbocharging System | Fixed Geometry Turbocharger (FGT) with Wastegate Bypass |
| Cooling Method | Oil-Cooled (journal bearing system with pressurized lubrication) |
| Lubrication Source | Engine oil (from main gallery) |
| Control Type | Pneumatically Actuated Wastegate Valve |
| Max Operating Speed | >100,000 RPM |
| Emission Compliance | Supports China V / China VI Emission Standards |
| Parameter | Value / Detail |
|---|---|
| Compressor Wheel Material | High-strength cast aluminum alloy; upgraded versions use MFS (machined/forged-swept) aluminum for improved fatigue resistance |
| Turbine Housing Material | Ni-resist ductile cast iron (high nickel content), withstands exhaust temps >750°C |
| Shaft Material | High-performance alloy steel, precision-ground and dynamically balanced |
| Bearing Type | Floating journal bearings (oil-lubricated) |
| Wastegate Type | Integrated pneumatic actuator – modulates boost pressure under high load |
| Boost Pressure Range | 1.8 – 2.6 bar (varies by engine calibration) |
| Airflow Capacity | ~45–65 kg/min (depending on operating point) |
| Efficiency (Compressor) | ≥75% peak adiabatic efficiency |
| Thermal Endurance | Designed for continuous operation in ambient temperatures from -30°C to +50°C |
| Service Life (typical) | 15,000 – 30,000 operating hours (with proper maintenance and oil management) |
Shacman Turbocharger Parts Reference Table
| Part Number | Part Name | Compatible Vehicle Models | Specification |
|---|---|---|---|
| Weichai WP10 Series (270-375HP) | |||
| 612601110954 / 4048381 | Turbocharger HX50W | F2000, F3000 (WP10/WD615, 290/336HP) | Holset HX50W, Wastegated, Euro III/IV |
| 612600118895 | Turbocharger HX40W | F3000 (WP10, 270/290HP) | Holset HX40W, 290HP High Pressure |
| 612601110960 | Turbocharger HX40W | F3000, M3000 (WP10) | Holset HX40W, Standard Type |
| 1000714569 | Turbocharger HX40 | X3000 (WP10 Euro V) | Holset HX40, Euro 5 Emission |
| 612601111007 | Turbocharger HX50W | F3000 (WP10, 336/375HP) | Holset HX50W, Higher HP Version |
| 612600118932 / 2839652 | Turbocharger HX50 | F2000, F3000 (WP10, 270/290/336HP) | Holset HX50, 270-336HP |
| Weichai WP12 Series (375-460HP) | |||
| 612630110581 / 612640110348 | Turbocharger GTA42 | F3000, X3000 (WP12, 375/400HP) | Garrett GTA42, 800992-0006, EFI |
| 6126300110020 / 768349-0003 | Turbocharger GTA42 | F3000 (WP12, 375HP) | Garrett GTA42, Original Type |
| 612630110258 | Turbocharger GTA42/HX50 | F3000, X3000 (WP12, 375/400HP) | GTA42 or HX50, 375HP |
| 612640110399 | Turbocharger GTA42 | F3000, X3000 (WP12 EFI) | Garrett GTA42, EFI Engine |
| 1000554640 | Turbocharger (BorgWarner) | WP12 Engines | BorgWarner Original, OEM |
| Weichai WP13 Series (480-550HP) | |||
| 1006105168 | Turbocharger B3G | X3000 (WP13, 550HP) | BorgWarner B3G, 550HP, Euro V |
| 1000874378 | Turbocharger B3G | X3000 (WP13, 430/500HP) | BorgWarner B3G, 430-500HP |
| 1000578628 / 13839700094 | Turbocharger B3G | X3000, F3000 (WP13, 500-550HP) | BorgWarner B3G, 500-550HP, 848239 |
| 1006074876 / 13879400056 | Turbocharger | WP13 Engines | Original Weichai, WP13G530E310 |
| 1005001212 / 899839-0004 | Turbocharger GTD1449 | X3000 (WP13 Euro VI) | Garrett GTD1449, Euro 6, National 6 |
| 1000322192 | Turbocharger | X3000 (WP13, 375/430HP) | Standard WP13 Turbo |
| Cummins ISM11/QSM11/M11 Series | |||
| 4046025 / 4046026 / 2843417 | Turbocharger HX55W | New M3000, X3000, F3000 (ISM11/QSM11) | Holset HX55W, 385-440HP, M11/ISM |
| 4037625 / 4089860 | Turbocharger HX55W | ISM11/QSM11 Engines | Holset HX55W, Cummins M11 |
| 3592778 / 3592783 | Turbocharger HX55W | M11/ISM11 Engines | Holset HX55W, Earlier Version |
| 4024963 / 3593597 | Turbocharger HX50W | ISM11/QSM11 Engines | Holset HX50W, 350-400HP |
| Universal / Other | |||
| 61800150015 | Turbocharger Assembly | F3000, X3000, M3000 | Universal Type, Aftermarket |
| 410800110124 | Turbocharger | WP10/WP12/WP13 Series | Replacement Type, Multi-engine |
| 1000406626 / 612630110752 | Turbocharger | X3000 | Original X3000 Type |
