| Quantity: | |
|---|---|
5205040AA01/A
FAW
| Attribute | Description |
|---|---|
| Product Name | Wiper Linkage Assembly / Windshield Wiper Transmission Mechanism |
| OE Part Number | 5205040AA01/A (or 5205040AA01A) |
| Function | Transmits rotational motion from motor to dual wiper arms via multi-link pivot system |
| Design Type | Dual-output mechanical linkage with three mounting points and self-aligning joints |
| Core Components | Main rod, sub-rods, dual output shafts, ball joints, rubber-damped brackets |
| Mounting Position | Installed beneath the cowl panel, connected to wiper motor and wiper arms |
| Application | Front wiper system on FAW J6-series heavy-duty trucks |
| Parameter | Specification |
|---|---|
| Material – Rod Body | High-strength cold-rolled carbon steel tubing |
| Material – Ball Joint Housing | Die-cast aluminum alloy or reinforced engineering plastic |
| Ball Joint Type | Self-lubricating composite bushings (PTFE-lined) for reduced friction and wear |
| Output Shafts | Dual splined shafts for secure attachment of left/right wiper arms |
| Surface Treatment | Black electrophoretic coating (e-coat) or zinc plating — excellent salt-spray corrosion resistance (>720 hours) |
| Structure | Multi-bar linkage including: |
