Trailer Parts
| Attribute | Description |
|---|---|
| Product Name | Trailer Differential Repair Kit |
| Common Names | Axle Overhaul Kit, Diff Seal & Bearing Kit, Rear End Repair Kit |
| Main Components Included | Bearings (tapered roller), oil seals, shims, gaskets, crush sleeves, O-rings |
| Compatibility | Single/Double Reduction Differentials;适用于 Meritor, Dana, BPW, SAF, etc. |
| Application | Commercial Trailers, Semi-Trailers, Dump Trucks, Heavy Haul Vehicles |
| Material | Chrome steel (bearings), Nitrile rubber (seals), brass/copper (shims), fiber/gasket paper |
| Standard Compliance | ISO 9001, SAE J615, DIN 720, GB/T Standards |
| Operating Temperature | -40°C to +150°C |
| Reusability | No – intended for one-time repair/service use |
| Packaging | Complete sealed kit with labeled parts |
| Installation Type | Requires professional disassembly and reassembly |
| Customization Available | Yes – by axle model, gear ratio, or regional specification |
| Parameter | Specification |
|---|---|
| Kit Model Number | DRK-M140 |
| Axle Brand Compatibility | Meritor MSA140, MX140, F140 |
| Bearings Included | Pinion Bearing (Front & Rear), Carrier Bearings (x2) |
| Oil Seal | Input Shaft Seal (Pinion Seal), Outer Axle Seals (optional) |
| Gasket Type | Differential Cover Gasket, Pinion Nut Lock Gasket |
| Shims | Thickness: 0.8mm, 1.0mm, 1.2mm, 1.5mm (set included) |
| Crush Sleeve / Spacer | One-time use collapsible sleeve for pinion preload |
| Bearing Preload Range | 0.5–1.5 N·m (as per OEM spec) |
| Seal Material | NBR (Nitrile Butadiene Rubber), heat-resistant up to 130°C |
| Bearing Precision Grade | P5 (high precision), tapered roller type |
| Torque Specifications | Follow OEM manual (e.g., Pinion Nut: 350–450 N·m) |
| Approvals | Meets Meritor 050-140-001, SAE J615 Rev. 3 |
