WD615 WD618
Weichai
| Parameter | Specification |
|---|---|
| Engine Type | Inline 6-cylinder, 4-stroke, water-cooled, direct injection |
| Aspiration | Turbocharged and Intercooled (on most variants) |
| Displacement | 9.726 liters (L) |
| Bore × Stroke | 126 mm × 130 mm |
| Compression Ratio | ~17.5:1 (typical) |
| Power Output Range | 176 kW to 323 kW (≈ 240 hp to 430 hp) depending on model |
| Peak Torque | Up to 2100 N·m at 1100–1600 rpm |
| Fuel System | Mechanical inline fuel injection pump (P-T or Bosch-type) |
| Emission Standard | Euro I / Euro II (equivalent to China National Stage II) |
| Specific Fuel Consumption | As low as 189 g/kW·h under optimal conditions |
| Dry Weight | Approx. 850 kg (1,874 lbs) |
| Cooling System | Liquid-cooled with radiator, thermostat, and water pump |
| Lubrication System | Full-pressure forced lubrication with spin-on oil filter |
| Starting Method | Electric starter motor (24V DC standard) |
| Governor Type | Mechanical or electro-mechanical (varies by version) |
| Valvetrain Configuration | OHV (Overhead Valve), pushrod actuated |
| Maintenance Design | "One Cylinder, One Valve Cover" — allows individual cylinder access |
 |  |
 | |
