| Quantity: | |
|---|---|
WG9716582301 DZ9X259712104
Shacman
| Attribute | Specification |
|---|---|
| Official Name | Electrical Junction Box Assembly / Main Fuse Box |
| Common Names | Central Power Distribution Module, Fuse & Relay Center |
| OEM Brand | SINOTRUK (China National Heavy Duty Truck Group) |
| Part Number | WG9716582301 |
| Voltage Rating | 24V DC (standard for heavy-duty commercial vehicles with dual batteries) |
| Housing Material | Flame-retardant engineering plastic: PBT or PA66 (polyamide) |
| Internal Components | - Multiple blade-type and bolt-on fuses (e.g., 20A, 70A) - Electromechanical relays (power switching) - Flasher modules and logic circuits - Pre-wired terminal blocks |
| Connector Type | Multi-pin plug-in connectors (rear-mounted), supporting CAN bus signals |
| Dimensions (L × W × H) | ~255 mm × 175 mm × 75 mm |
| Weight | Approx. 1.6 kg – 1.8 kg (bare unit); ~8.0 kg with packaging |
| Protection Level | IP65 or higher — dust-tight and protected against water jets |
| Operating Temperature Range | -40°C to +105°C |
| Function | Power distribution, circuit protection, relay control, signal routing |
| Origin | Jinan, Shandong Province, China |
