| Quantity: | |
|---|---|
1119ZD2A-030
Dongfeng
| Attribute | Specification |
|---|---|
| Product Name | Fuel Water Separator Filter / Primary Diesel Fuel Filter |
| Manufacturer | Dongfeng Commercial Vehicles Co., Ltd. (OEM); commonly co-developed with Fleetguard |
| Primary Part Number | 1119ZD2A-030 |
| Alternative Names | Fuel Filter, Water-in-Fuel Separator, Spin-On Fuel Canister |
| Filter Type | Full-flow, spin-on disposable design |
| Mounting Style | Threaded base with O-ring seal; direct screw-on installation |
| Function | Removes water and solid contaminants from diesel fuel |
| Filtration Principle | Depth filtration + coalescing technology for water separation |
| Housing Material | Reinforced steel shell with corrosion-resistant coating |
| Sealing Method | Nitrile rubber O-ring (approx. 90mm OD, 80mm ID) |
| Application Class | Heavy-Duty Diesel Engines – Trucks, Construction Equipment, Generators |
| Parameter | Value / Detail |
|---|---|
| Overall Height | 264–274 mm (10.4–10.8 inches) |
| Outer Diameter (OD) | 108–110 mm (4.25–4.33 inches) |
| Thread Size | 1" - 14 UNS (Unified National Special thread) |
| Seal Dimensions | |
| - O-ring Outer Diameter | ~90.4 mm |
| - O-ring Inner Diameter | ~80.4 mm |
| Filter Media | Multi-layer synthetic paper or StrataPore®-type composite material |
| Filtration Efficiency | ≥ 99.99% at 10 microns (nominal), down to 4–5 µm absolute |
| Water Separation Efficiency | > 95% of free and emulsified water under standard flow conditions |
| Maximum Working Pressure | Up to 7 bar (100 psi) |
| Operating Temperature Range | -30°C to +120°C (-22°F to +248°F) |
| Inlet/Outlet Port Sizes | Compatible with M14×1.5, M16×1.5, or M18×1.5 fuel lines |
| Drain Feature | Bottom-mounted drain valve or transparent water collection bowl (depending on housing) |
| Recommended Replacement Interval | Every 8,000–20,000 km (based on fuel quality and operating environment) |
