| Quantity: | |
|---|---|
1862215032
Yutong Bus Parts
| Attribute | Specification |
|---|---|
| Part Number (P/N) | 1862215032 |
| Brand | SACHS (ZF/Schaeffler) |
| Alternate Designation | 430WGTZ (430 = OD in mm; WGTZ = structural type code) |
| Product Name | Clutch Disc / Driven Plate / Friction Plate |
| Application Type | Heavy-Duty Commercial Vehicles – Coaches & Trucks |
| Outer Diameter | 430 mm |
| Inner Diameter (Friction Ring) | ~290 mm |
| Number of Splines | 10 teeth |
| Spline Bore Size | 44.5 mm × 51 mm (Standard 2" - 10N profile) |
| Friction Material | Asbestos-Free Organic Composite with High Copper Content |
| Damping System | Multi-Stage Torsional Vibration Damper (Dual/Multi-Spring System) |
| Weight (Approx.) | 8.9 kg – 9.8 kg |
| EAN Barcode | 4013872047284 |
| OE Quality Level | OEM Standard – Meets or Exceeds Manufacturer Specifications |
| Parameter | Detail |
|---|---|
| Torque Capacity | Designed for engines exceeding 1,400 N·m input torque |
| Friction Performance | Stable coefficient of friction across wide temperature range (-20°C to +400°C surface temp) |
| Heat Resistance | High thermal conductivity materials reduce risk of glazing and fade during frequent starts/stops |
| Torsional Damping | Advanced multi-stage spring system absorbs engine torsional vibrations, protecting transmission gears |
| Engagement Smoothness | Optimized damping stages ensure soft start-up and reduced driveline shock |
| Operating Environment | Suitable for severe service: city bus cycles, mountain routes, long-distance hauling |
| Compliance Standards | ECE R75 Certified, ISO/TS 16949 Production Control, RoHS Compliant |
| Service Life Expectancy | Up to 300,000 km under normal operation; highly dependent on driving style and maintenance |
| Attribute | Specification |
|---|---|
| Part Number (P/N) | 1862215032 |
| Brand | SACHS (ZF/Schaeffler) |
| Alternate Designation | 430WGTZ (430 = OD in mm; WGTZ = structural type code) |
| Product Name | Clutch Disc / Driven Plate / Friction Plate |
| Application Type | Heavy-Duty Commercial Vehicles – Coaches & Trucks |
| Outer Diameter | 430 mm |
| Inner Diameter (Friction Ring) | ~290 mm |
| Number of Splines | 10 teeth |
| Spline Bore Size | 44.5 mm × 51 mm (Standard 2" - 10N profile) |
| Friction Material | Asbestos-Free Organic Composite with High Copper Content |
| Damping System | Multi-Stage Torsional Vibration Damper (Dual/Multi-Spring System) |
| Weight (Approx.) | 8.9 kg – 9.8 kg |
| EAN Barcode | 4013872047284 |
| OE Quality Level | OEM Standard – Meets or Exceeds Manufacturer Specifications |
| Parameter | Detail |
|---|---|
| Torque Capacity | Designed for engines exceeding 1,400 N·m input torque |
| Friction Performance | Stable coefficient of friction across wide temperature range (-20°C to +400°C surface temp) |
| Heat Resistance | High thermal conductivity materials reduce risk of glazing and fade during frequent starts/stops |
| Torsional Damping | Advanced multi-stage spring system absorbs engine torsional vibrations, protecting transmission gears |
| Engagement Smoothness | Optimized damping stages ensure soft start-up and reduced driveline shock |
| Operating Environment | Suitable for severe service: city bus cycles, mountain routes, long-distance hauling |
| Compliance Standards | ECE R75 Certified, ISO/TS 16949 Production Control, RoHS Compliant |
| Service Life Expectancy | Up to 300,000 km under normal operation; highly dependent on driving style and maintenance |
