Genuine Original Product Wiper Motors Are Suitable for Zhongtong Yutong Kinlong Higer Buses

Genuine Original Product Wiper Motors Are Suitable for Zhongtong Yutong Kinlong Higer Buses

The WB5205-0031 is a heavy-duty electric wiper motor assembly specifically engineered for large and medium-sized commercial coaches. As a core actuator in modern bus windshield cleaning systems, it ensures reliable and uninterrupted visibility under extreme weather conditions such as torrential rain, snow, or sleet. In 2026, this high-torque 24V DC motor remains a standard-fit solution across major Chinese bus OEMs including Yutong, Kinglong, Higer, and Zhongtong. Designed to drive long wiper arms on expansive windshields of 10–12 meter coaches, the WB5205-0031 delivers powerful performance, dual-speed operation, low-noise running, and intelligent auto-parking functionality — making it an essential component for safe all-weather operation.

Quantity:
Availability:





Inquire Add to Basket

Model:
WB5205-0031
Brand:
Yutong Bus Parts

Product Description

Attribute	Specification
Part Number	WB5205-0031
Application	Heavy-Duty Passenger Coaches / Buses
Voltage Rating	24 V DC
Rated Power	150W – 180W (High-Power Design)
Speed Modes	Dual-Speed: Low Speed ≥ 35 rpm, High Speed ≥ 55 rpm
Output Torque	Starting Torque > 40 N·m
Rotation Type	Unidirectional Rotation (typically drives linkage mechanism)
Auto Return Function	Yes – Integrated Auto-Parking (returns wipers to bottom park position when off)
Protection Class	IP66 (Dust-tight & Protected against powerful water jets)
Connector Type	5-Wire Plug (Common, Low Speed, High Speed, Park Power, Park Signal)
OEM Fitment	Yutong, Kinglong, Higer, Zhongtong

Parameter	Detail
Operating Voltage Range	20–30 V DC (compatible with vehicle voltage fluctuations)
Motor Type	Permanent Magnet DC Motor with Gear Reduction
Gear Mechanism	Precision Ground Worm Gear & Wheel (low noise, high durability)
Direction Control	Single Direction Output; Oscillation Achieved via Linkage System
Auto-Park Feature	Built-in parking switch ensures blades return to base position after OFF
Thermal Protection	Internal thermal overload protector (auto-reset)
Noise Level	< 65 dB(A) under normal operation (optimized for passenger comfort)
Service Life	≥ 500,000 cycles (under standard test conditions)
Mounting Style	Flange Mount (standardized interface for coach windshield integration)
