Shacman
| Attribute | Details |
|---|---|
| Part Name | Instrument Panel Assembly / Dashboard Cluster / Gauge Cluster / Instrument Cluster |
| Type | Original Equipment (OE), Aftermarket Replacement, or High-Quality Replica |
| Voltage Rating | 24V DC (standard for heavy-duty trucks); 12V DC (light-duty vehicles) |
| Display Type | Analog dials with digital LCD/TFT screen (hybrid), or fully digital display (in newer models) |
| Warning & Indicator Lights | Engine fault (Check Engine), ABS, Low Oil Pressure, Low Air Pressure, Battery Charge, Seatbelt, Door Open, Parking Brake, etc. |
| Communication Interface | CAN bus (Controller Area Network) – typically CAN 2.0B @ 250kbps or 500kbps |
| Backlighting | LED illumination (white or blue tone), adjustable brightness |
| Housing Material | High-strength engineering plastic (ABS/PC blend), heat-resistant and impact-durable |
| Mounting Location | Directly behind the steering wheel on the dashboard |
| Origin | China (common manufacturing base for Sinotruk, SHACMAN, FAW, etc.) |
| Warranty | Typically 6 to 12 months depending on supplier |
Name1
Name2
Verify Compatibility Before Purchase
Confirm physical dimensions, button layout, gauge style, and software compatibility. Even small differences can prevent proper installation.
Disconnect Battery Before Work
Always disconnect the negative terminal of the battery before removing or installing the cluster to avoid short circuits or ECU errors.
Professional Installation Required
Involves dashboard disassembly, wiring harness connection, and sometimes ECU calibration or programming (especially for digital clusters).
Handle with Care – Sensitive Electronics
Avoid static discharge, drops, or moisture exposure. Do not touch circuitry directly.
Ensure Proper Grounding & Power Supply
Poor grounding can cause erratic gauge behavior or flickering displays.
Programmable Clusters May Need Configuration
Some digital units require:
VIN input
Odometer initialization
Language setting
Unit conversion (km/h ↔ mph) Use diagnostic tools (e.g., Sinotruk TechTool, Delphi DS150E) if needed.
Test All Functions After Installation
Check:
All gauges respond correctly
Warning lights illuminate during startup (bulb check)
Digital display shows accurate data
Backlighting works at all brightness levels
Avoid Liquid and Dust Ingress
Keep the front lens clean and dry. Moisture inside can cause condensation and corrosion.
Do Not Disassemble Internally
The unit is sealed. Opening it may damage internal components and void warranty.
Use Genuine or High-Quality Replacements Only
Cheap clones often have inaccurate readings, poor build quality, or incompatible firmware.
