| Quantity: | |
|---|---|
WG9112540174
Sinotruk HOWO
| Attribute | Specification |
|---|---|
| Official Name | Muffler Bracket Assembly / Exhaust Silencer Support Hanger |
| Common Names | Muffler Mount, Exhaust Support Bracket, Silencer Cradle |
| OEM Brand | SINOTRUK (China National Heavy Duty Truck Group) |
| Part Number | WG9112540174 |
| Material | High-strength carbon structural steel (Q235 or equivalent grade) |
| Surface Treatment | Electrophoretic coating (E-coat) or high-temperature anti-rust paint |
| Structure Type | Bent-welded frame with multiple bolt holes for chassis attachment |
| Load Capacity | Designed to support muffler assemblies weighing 20–40 kg under dynamic conditions |
| Compatibility | Fits standard Φ400 mm – Φ500 mm diameter mufflers and aftertreatment units |
| Weight | Approx. 3.5 kg – 5.0 kg |
| Design Features | - Multi-point fastening to frame rails - Reinforced stress zones at weld joints - Clearance for rubber isolators or vibration dampeners |
| Durability | Resists fatigue cracking under continuous vibration and thermal exposure |
| Quality Standard | Complies with ISO 9001, TS16949, and China VI emission system requirements |
| Origin | Jinan, Shandong Province, China |
Name1
Name2
Confirm correct model: Verify WG9112540174 matches your truck’s configuration via SINOTRUK EPC system.
Inspect new bracket: Check for deformation, cracked welds, or damaged threads.
Prepare mounting area: Clean frame rail surface; remove rust, oil, or old sealant.
Gather hardware: Use original-grade bolts, washers, and lock nuts (typically M12–M14).
Position the Bracket:
Align with pre-drilled holes on the chassis side rail.
Ensure clearance from brake lines, fuel pipes, and wiring harnesses.
Insert Fasteners:
Insert high-strength bolts through both bracket and frame.
Add flat and spring washers if specified.
Torque Properly:
Tighten diagonally in stages.
Final torque: 80–100 N·m (confirm exact value in service manual).
Install Muffler Onto Bracket:
Lower muffler into place using hoist or support tool.
Secure with clamp (WG9112540018) and rubber pads (if equipped).
Final Inspection:
Visually check alignment and stability.
Shake muffler gently — no excessive movement should occur.
