3801010-C0110
Dongfeng
| Attribute | Specification |
|---|---|
| Product Name | Combination Instrument Cluster / Dashboard Assembly |
| Manufacturer | Dongfeng Commercial Vehicles Co., Ltd. (OEM) |
| Primary Part Number | 3801010-C0110 |
| Alternative Names | Vehicle Instrument Panel, Gauge Cluster, Dash Meter |
| Operating Voltage | 24V DC nominal (range: 18–32V) |
| Display Type | Hybrid: Analog dials + Digital LCD screen |
| Communication Protocol | CAN Bus (SAE J1939 standard) |
| Backlight Color | Amber or emerald green (varies by production batch) |
| Brightness Control | Manual adjustment or automatic ambient light sensing |
| Housing Material | Flame-retardant engineering plastic with anti-glare faceplate |
| Mounting Location | Behind steering wheel, integrated into dashboard frame |
| Application Class | Medium- to Heavy-Duty Commercial Trucks |
| Parameter | Value / Detail |
|---|---|
| Main Gauges | |
| - Speedometer | 0–160 km/h (or 0–100 mph) |
| - Tachometer | 0–3000 RPM (redline varies by engine calibration) |
| - Water Temperature Gauge | Cold → Hot range; warns at high temp |
| - Fuel Level Gauge | E – F scale |
| - Dual Air Pressure Gauges | Brake circuits I & II (0–12 bar) |
| - Oil Pressure Indicator | Warning light only (no analog dial) |
| Digital LCD Display Functions | |
| - Odometer / Trip Meter | Cumulative and resettable |
| - Real-Time Fuel Consumption | L/100km or mpg |
| - Urea (AdBlue) Level | Percentage remaining |
| - Time & Date | Adjustable via button controls |
| - Diagnostic Trouble Codes (DTCs) | Displays fault messages when triggered |
| Warning Indicators | ABS, Engine Fault, Charging, Preheat, Seat Belt, Door Ajar, etc. |
| Audible Alerts | Built-in buzzer for low-pressure, door-open, and seatbelt alerts |
| Environmental Operating Range | -40°C to +85°C (-40°F to +185°F) |
| Vibration Resistance | Complies with QC/T 417 and GB/T 28046 standards |
| Weight | Approx. 3.5 kg (7.7 lbs) |
| Connector Type | Multi-pin waterproof plug (typically 20+ pins) |
