5038668AB
FAW
| Attribute | Description |
|---|---|
| Product Name | Engine Water Pump (Cooling System) |
| Brand / Manufacturer | Genuine Mopar (FCA US LLC – Original Equipment) |
| Type | Belt-driven centrifugal water pump |
| Function | Circulates engine coolant to maintain optimal thermal balance |
| Application | Front-mounted on V8 engine timing cover or front housing |
| Housing Material | High-grade die-cast aluminum – lightweight and corrosion-resistant |
| Impeller Material | Stamped steel or cast iron – durable and efficient |
| Drive Mechanism | Driven by serpentine belt via crankshaft pulley |
| Included Components | Typically supplied with pump body, gasket, freeze plug (core plug), and integrated coolant temperature sensor |
| Quality Standard | Meets FCA/Mopar OE specifications; tested for leak integrity, bearing life, and hydraulic performance |
Name1
Name2
| Parameter | Value / Detail |
|---|---|
| OEM Part Number | 5038668AB |
| Replaced By / Updated To | 68346915AA, 68346916AA (latest service replacements) |
| Weight | Approx. 11.2 lbs (5.08 kg) |
| Dimensions (L × W × H) | 16.2" × 16.3" × 6.6" (approx. 41.1 cm × 41.4 cm × 16.8 cm) |
| Mounting Pattern | Direct bolt-on design; matches OEM locations on 5.7L/6.4L HEMI engines |
| Flow Rate | Optimized for HEMI V8 cooling demands (~50–70 GPM at rated RPM) |
| Bearing Type | Sealed ball bearing with extended service life |
| Sealing Method | Mechanical face seal + rubber O-ring/gasket set |
| Sensor Integration | Built-in engine coolant temperature (ECT) sensor in some configurations |
| Operating Temperature Range | -30°C to +120°C (engine coolant environment) |
| Attribute | Description |
|---|---|
| Product Name | Engine Water Pump (Cooling System) |
| Brand / Manufacturer | Genuine Mopar (FCA US LLC – Original Equipment) |
| Type | Belt-driven centrifugal water pump |
| Function | Circulates engine coolant to maintain optimal thermal balance |
| Application | Front-mounted on V8 engine timing cover or front housing |
| Housing Material | High-grade die-cast aluminum – lightweight and corrosion-resistant |
| Impeller Material | Stamped steel or cast iron – durable and efficient |
| Drive Mechanism | Driven by serpentine belt via crankshaft pulley |
| Included Components | Typically supplied with pump body, gasket, freeze plug (core plug), and integrated coolant temperature sensor |
| Quality Standard | Meets FCA/Mopar OE specifications; tested for leak integrity, bearing life, and hydraulic performance |
Name1
Name2
| Parameter | Value / Detail |
|---|---|
| OEM Part Number | 5038668AB |
| Replaced By / Updated To | 68346915AA, 68346916AA (latest service replacements) |
| Weight | Approx. 11.2 lbs (5.08 kg) |
| Dimensions (L × W × H) | 16.2" × 16.3" × 6.6" (approx. 41.1 cm × 41.4 cm × 16.8 cm) |
| Mounting Pattern | Direct bolt-on design; matches OEM locations on 5.7L/6.4L HEMI engines |
| Flow Rate | Optimized for HEMI V8 cooling demands (~50–70 GPM at rated RPM) |
| Bearing Type | Sealed ball bearing with extended service life |
| Sealing Method | Mechanical face seal + rubber O-ring/gasket set |
| Sensor Integration | Built-in engine coolant temperature (ECT) sensor in some configurations |
| Operating Temperature Range | -30°C to +120°C (engine coolant environment) |
