AZ1630840014
Sinotruk HOWO
| Attribute | Specification |
|---|---|
| Part Name | Heater Blower Motor Assembly / HVAC Fan Motor / Cabin Blower Unit |
| OEM Part Number | AZ1630840014 Common variant: AZ1630840014-1 (often includes impeller/wheel) |
| Voltage Rating | 24V DC (standard for Chinese commercial vehicles) |
| Motor Type | Permanent Magnet DC Motor (PMDC) |
| Construction | • Stator: High-purity copper winding • Rotor: Balanced armature with commutator • Bearings: Sealed ball bearings (premium version) or oil-impregnated sleeve bearings |
| Impeller (Fan Wheel) | Centrifugal-type plastic fan blade (ABS/PP flame-retardant material), dynamically balanced |
| Housing Material | Heat-resistant engineering plastic with vibration-damping design |
| Mounting Style | Screw-mounted into heater box (HVAC case) via flange |
| Airflow Output | High-volume centrifugal design — supports multi-speed cabin ventilation |
| Speed Control | External resistor module or electronic speed controller (not built-in) |
| Weight | Approx. 1.75 kg – 2.1 kg |
| Dimensions (Packaging) | ~25 cm × 18 cm × 18 cm (varies by packaging type) |
| Operating Temperature Range | -40°C to +80°C |
| Certifications | ISO9001, GB/T standards for automotive electrical components |
| Warranty | Typically 6–12 months (genuine OEM); shorter for aftermarket |
Name1
Name2
Due to its location within the HVAC system, proper installation requires care to avoid damage.
Power Off: Disconnect battery negative terminal before starting work.
Drain Moisture: Ensure no standing water in HVAC case (common after rain or clogged drain tube).
Inspect Old Motor: Check for burnt windings, seized bearing, or melted connector.
Verify New Unit: Confirm impeller spins freely and wiring is intact.
Access the blower motor — usually from under the dashboard or passenger footwell.
Unplug the 2-pin electrical connector (typically red/black wires).
Remove 3–4 mounting screws securing the motor to the heater box.
Gently pull out the old motor and impeller.
Insert the new AZ1630840014(-1) unit — align shaft with impeller bore.
Reinstall screws evenly; do not overtighten.
Reconnect the power plug securely.
Restore power and test all fan speeds via dash switch.
