WG2229210041
Sinotruk HOWO
| Attribute | Specification |
|---|---|
| Official Name | Selector Support Rod / Shift Control Link Rod |
| Common Names | Gear Selector Link, Transmission Support Rod, Shifter Tie Rod |
| OEM Brand | SINOTRUK (China National Heavy Duty Truck Group) |
| Part Number | WG2229210041 |
| Material | High-quality medium-carbon steel 45# or alloy structural steel |
| Surface Treatment | Zinc plating or electrophoretic coating for corrosion resistance |
| Total Length | ~330 mm – 350 mm (varies slightly by production batch) |
| Rod Diameter | ~16 mm – 18 mm |
| Connection Type | Threaded ends or spherical ball joints; some versions feature adjustable length |
| Weight | Approx. 0.8 kg – 1.2 kg |
| Structure | Rigid tubular or solid bar design with wear-resistant bushings or ball studs at both ends |
| Function | Transmits lateral/axial motion from cab shifter to gearbox selector shaft |
| Design Life | Up to 300,000 km under normal operating conditions |
| Origin | Jinan, Shandong Province, China |
Name1
Name2
Confirm correct model: Use SINOTRUK EPC system to verify compatibility with your VIN/chassis.
Inspect new rod: Check for bent shafts, stripped threads, damaged ball joints, or cracked dust boots.
Clean mounting areas: Remove rust, dirt, old grease, and debris from pivot points.
Prepare tools: Torque wrench, open-end wrenches, hammer (for removal only), protective gloves.
Remove Old Support Rod (WG2229210041):
Loosen lock nuts and disconnect clevis pins.
Extract carefully without damaging surrounding components.
Position New Rod:
Align with selector arm and intermediate linkage.
Ensure no binding or interference with frame or wiring.
Install Clevis Pins & Washers:
Insert through eyes of rod and arm.
Add flat and spring washers if specified.
Secure with Lock Nuts:
Tighten to recommended torque: Typically 30–40 N·m
Apply thread locker if required.
Adjust Length (if applicable):
Rotate threaded end to match original center-to-center dimension.
Recheck alignment after adjustment.
Final Inspection:
Manually move linkage — should operate smoothly without play or stiffness.
Test all gears from inside cab — ensure full engagement and neutral return.
